| Category | Details |
|---|---|
| Testing & Packaging | Program and functional test and package for free |
| Quality Standard | IPC - A - 610E standard, E - test, X - ray, AOI test, QC, 100% functional test |
| Professional Services | PCB Layout, PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, PCB Assembly, Housing and assembly, Box Building, OEM Service |
| Certifications | 94v - 0, CE, SGS, FCC, RoHS, ISO9001, ISO14001, ISO13485, TS16949 |
| Warranty Period | 2 - year warranty for PCBA |
| Factory Configuration | 16 SMT Lines, 4 DIP Lines, 1 X - Ray, 32 AOI, 2 Sample test machines |
| Specifications - Material | FR4, High Tg FR4, Lead - Free Solder Sheet, Halogen Free, Ceramic Filling, PI, BT, PPO, PPE etc. |
| Board Thickness | Mass production: 10mm; Samples: 17.5mm |
| Surface Finish | HASL, Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
| Max Panel Size | 1150mm × 560mm |
| Number of Layers | Mass production: 2 - 58 layers; Pilot run: 64 layers; Flexible PCB: 1 - 12 Layers |
| Min Hole Size | Mechanical drill: 0.2mm; Laser drill: 0.075mm |
| PCBA QC | X - Ray, AOI Test, Functional Test |
| SMT Capacity | 700 Million Points/Day |
| DIP Capacity | 5 Million Points/Day |
